    MLC5205A non-contact dynamic torque sensor MLC5205A non-contact dynamic torque sensor
    MLC5205A non-contact dynamic torque sensor
    MLC5205A non-contact dynamic torque sensor-MANYYEAR TECHNOLOGY
    MLC5205A non-contact dynamic torque sensor-MANYYEAR TECHNOLOGY
    MLC5205A non-contact dynamic torque sensor-MANYYEAR TECHNOLOGY
    MLC5205A non-contact dynamic torque sensor-MANYYEAR TECHNOLOGY

    MLC5205A non-contact dynamic torque sensor

    Dynamic Torque Sensor Torque Sensor 3999 0

    MLC5205A non-contact Dynamic torque sensor

    MODEL: MLC5205A
    category:Torque Sensr
    Range: 3,5,10,20,30,50,100Nm
    Material: alloy steel
    Apllication: dynamic torque measurement, railway locomotive power, car power, tractor power, aircraft power, ship power, mining machinery power, sewage treatment system

    we have prepared this form as below, hoping to help you.if you complete the sheet, please send to admin@manyyear.com. we will reply to you in 24Hr.

      Product selection reference

    Online Sales

    Product Introduction Technical Documents



    Product Picture Reference

    MLC5205A non-contact dynamic torque sensor-MANYYEAR TECHNOLOGY

    Technology Specification

    Below spec is only for customer design reference. we can provide ODM product.
    MLC5205A non - contact Dynamic torque sensor

    Range3，5，10，20，30，50，100NmStability0.25%/
    workvoltage±15V DC for freq output、24V DC for DC/DA output）insulation≥2000MΩ(100VDC)
    Signal output5～15Khz、4～20mA、1～5V、0-10Vtemperature-20～60℃（ Customizabler high temp. -20～120℃）
    Speed0～1000、3000、6000、8000 CL/minhumidity0～90%RH
    Speed signalStandard Product without measuring speed, if the measured speed increased 30mm in lengthoverload150%
    precision±0.25%、±0.5%Response time1ms

    Product Dimension

    MLC5205A non-contact dynamic torque sensor-MANYYEAR TECHNOLOGY

    Force Structure & Assembly Reference

    MLC5205A non-contact dynamic torque sensor-MANYYEAR TECHNOLOGY

    Product Application

    MLC5205A non-contact dynamic torque sensor-MANYYEAR TECHNOLOGYMLC5205A non-contact dynamic torque sensor-MANYYEAR TECHNOLOGYMLC5205A non-contact dynamic torque sensor-MANYYEAR TECHNOLOGY
