MLC508 – through-shaft gasket type ring load cell 5000kg

Model: MLC508
Category: Ring load cell
Rated load: 100, 200, 300, 500, 1000, 2000, 3000, 5000kg
Material: alloy steel
Safe overload: 120% FS; ultimate overload: 150% FS
Features: Ring load cell, gasket load cell , axial force sensor, extrusion force sensor, preload force sensor

we have prepared this form as below, hoping to help you.if you complete the sheet, please send to admin@manyyear.com. we will reply to you in 24Hr.

Product selection reference

Online Sales

Product Introduction Product Parameters

Product Picture Reference

Technology Specification

Below spec is only for customer design reference,we can provide ODM product.

washer force sensor, Circle load cell, Ring gasket load cell, compression load cell, Axial force sensor.

MLC508 - through-shaft gasket type ring load cell 500kg Model: MLC508 Category: Ring load cell Rated load: 100, 200, 300, 500, 1000, 2000, 3000, 5000kg Material: alloy steel Safe overload: 120% FS; ultimate overload: 150% FS Features: Ring load cell, gasket load cell , axial force sensor, extrusion force sensor, preload force sensor

Specification
Comprehensive error:	0.05%FS	Output resistance:	352±5Ω
Rated output:	1.0±0.002mV/V	Insulation resistance:	≥5000MΩ(100VDC)
Non-linearity:	0.02%FS	Excitation voltage:	9~15VDC
Hysteresis:	0.02%FS	Compensated temp:	-10~+40℃
Repeatability:	0.02%FS	Use temperature:	-40~+80℃
Creep:	0.02%FS/10Min	Temp effect on zero:	0.03%FS/10℃
Zero balance:	±1%FS	Temp effect on span:	0.02%FS/10℃
Input resistance:	380±5Ω	Defend grade:	IP68

Product Dimension

Force Structure & Assembly Reference
