MLC202 axle scale spoke load cell

2021/11/09 Force Load Cell MLC200 Button Load Cell 2739 0

axle scale load cell, warehouse scale load cell, spoke load cell

Model:ML202
Category: Button load cell
Range: 2.5t, 5t, 7.5t, 10t, 15t, 30t, 50t
Dimension: 104.6*100mm; 122*147mm; 138*155mm
Material: alloy steel, stainless steel
Characteristic: axle scale load cell, warehouse scale load cell, experimental machine force sensor

we have prepared this form as below, hoping to help you.if you complete the sheet, please send to admin@manyyear.com. we will reply to you in 24Hr.

Product selection reference

Online Sales

Product Introduction Product Parameters

Product Picture Reference

Technology Specification

Below spec is only for customer design reference. we can provide ODM product.

MLC202 axle scale spoke load cell

Model:ML202 Category: Button load cell Range: 2.5t, 5t, 7.5t, 10t, 15t, 30t, 50t Dimension: 104.6100mm; 122147mm; 138*155mm Material: alloy steel, stainless steel Characteristic: axle scale load cell, warehouse scale load cell, experimental machine force sensor

Other Dimension
Load range	D	H1	H2	H	D1	D2	D3
5,10ton	104.6	19.2	45.3	100	21.5	19.5	37
25,50,60ton	122	25	54	147	25	40	50
100ton	138	30	57	155	25	40	50
Specification
Comprehensive error:		0.05%FS		Output resistance:		700±10Ω
Rated output:		2±0.002mV/V		Insulation resistance:		≥5000MΩ(100VDC)
Non-linearity:		0.05%FS		Excitation voltage:		9~12VDC
Hysteresis:		0.02%FS		Compensated temp:		-10~+40ºC
Repeatability:		0.01%FS		Use temperature:		-35~+65ºC
Creep:		0.03%FS/10Min		Temp effect on zero:		0.03%FS/10ºC
Zero balance:		±1%FS		Temp effect on span:		0.02%FS/10ºC
Input resistance:		700±10Ω		Defend grade:		IP66

Product Dimension

Force Structure & Assembly Reference
