MLC165 pin force load cell

2024/06/18 Force Load Cell MLC100 Bridge Load Cell 3515 0

safety limiter weight sensor, overload load cell, pin load cell, pin force load cell

Model: MLC165
Category: Bridge load cell
Range: 150t, 200t, 300t, 500t, 750t
Size: Φ 280 * 720mm
Material: alloy steel, stainless steel
Characteristic: safety limiter load cell, overload load cell, pin load cell, pin force sensor

we have prepared this form as below, hoping to help you.if you complete the sheet, please send to admin@manyyear.com. we will reply to you in 24Hr.

Product selection reference

Online Sales

Product Introduction Product Parameters

Product Picture Reference

bridge load cell

MLC162 pin force load cell

Technology Specification

Below spec is only for customer design reference,we can provide ODM product.

MLC165 pin force load cell

Model: MLC165 Category: Bridge load cell Range: 150t, 200t, 300t, 500t, 750t Size: Φ 280 * 720mm Material: alloy steel, stainless steel Characteristic: safety limiter load cell, overload load cell, pin load cell, pin force sensor






Specification
Comprehensive error:	0.5%FS	Output resistance:	702±5Ω
Rated output:	1.0±0.005mV/V	Insulation resistance:	≥5000MΩ(100VDC)
Non-linearity:	0.05%FS	Excitation voltage:	9~12VDC
Hysteresis:	0.05%FS	Compensated temp:	-10~+40℃
Repeatability:	0.03%FS	Use temperature:	-20~+55℃
Creep:	0.03%FS/10Min	Temp effect on zero:	0.05%FS/10℃
Zero balance:	±1%FS	Temp effect on span:	0.05%FS/10℃
Input resistance:	750±10Ω	Defend grade:	IP66 & IP68

Product Dimension

bridge load cell

Force Structure & Assembly Reference
